ELECTRICAL/POWERTRAIN CONTROL for 2016 Scion iA

Select POWERTRAIN CONTROL Part

2016 Scion iA

Change vehicle

No. Part # Part # / Description List Price Price
1 77740-WB001 77740-WB001 / Vapor Canister

$207.81 $152.41
2 77751-WB001 77751-WB001 / Mount Bracket

#1

$4.55 $3.34
3 77751-WB003 77751-WB003 / Mount Bracket

#2

$4.55 $3.34
4 77751-WB002 77751-WB002 / Mount Bracket

#3

$6.75 $4.95
5 77751-WB004 77751-WB004 / Mount Bracket

#4

$4.55 $3.34
6 90118-WB720 90118-WB720 / Pressure Valve

$63.04 $46.24
7 77746-WB001 77746-WB001 / Filter

$1.44 $1.06
8 77404-WB001 77404-WB001 / Vent Hose

$212.30 $155.71
9 77701-WB001 77701-WB001 / Canister Hose

#1

$30.80 $22.59
10 77759-WB002 77759-WB002 / Canister Hose

#2

$16.51 $12.10
11 77759-WB001 77759-WB001 / Connector Hose

$57.11 $41.88
12 77233-WB001 77233-WB001 / Connector Hose Joint

$3.91 $2.87
13 25860-WB001 25860-WB001 / Vacuum Switch

Vacuum Valve

$82.46 $60.48
13 25860-WB001 25860-WB001 / Vacuum Switch

IA

$82.46 $60.48
14 25861-WB001 25861-WB001 / Vacuum Valve Bracket

$19.54 $14.34
15 25719-WB001 25719-WB001 / Vacuum Tank

$11.16 $8.19
16 23827-WB001 23827-WB001 / Vacuum Hose

$31.75 $23.29
17 12205-WB001 12205-WB001 / Vent Chamber

$36.50 $26.77
18 12255-WB001 12255-WB001 / Vent Chamber Gasket

$5.62 $4.12
19 12204-WB001 12204-WB001 / Vent Valve

$10.87 $7.98
19 12204-WB001 12204-WB001 / Vent Valve

PCV Valve

IA

$10.87 $7.98
20 90118-WB417 90118-WB417 / Vent Valve O-Ring

$6.09 $4.47
21 90118-WB749 90118-WB749 / Vent Valve Retainer

$6.92 $5.08
22 89467-WB001 89467-WB001 / Oxygen Sensor

Ft Oxygen Sensor

$176.29 $129.31
22 89467-WB001 89467-WB001 / Oxygen Sensor

IA; FRONT

$176.29 $129.31
23 89465-WB001 89465-WB001 / Oxygen Sensor

Rear Oxygen Sensor

$139.80 $102.54
23 89465-WB001 89465-WB001 / Oxygen Sensor

IA; REAR

$139.80 $102.54
No. Part # Part # / Description List Price Price
1 16400-WB001 16400-WB001 / Radiator Assembly

$357.80 $262.42
2 90118-WB831 90118-WB831 / Radiator Assembly Upper Bracket

Radiator Assembly Upper Bracket, LEFT

$4.30 $3.15
2 90118-WB831 90118-WB831 / Radiator Assembly Upper Bracket

Radiator Assembly Upper Bracket, RIGHT

$4.30 $3.15
3 16523-WB001 16523-WB001 / Radiator Assembly Upper Insulator

Radiator Assembly Upper Insulator, RIGHT

$6.90 $5.06
3 16523-WB001 16523-WB001 / Radiator Assembly Upper Insulator

Radiator Assembly Upper Insulator, LEFT

$6.90 $5.06
4 90118-WB466 90118-WB466 / Radiator Assembly Lower Bracket

Radiator Assembly Lower Bracket, LEFT

$11.96 $8.77
4 90118-WB466 90118-WB466 / Radiator Assembly Lower Bracket

Radiator Assembly Lower Bracket, RIGHT

$11.96 $8.77
5 16401-WB001 16401-WB001 / Radiator Cap

$21.81 $15.99
6 16417-WB001 16417-WB001 / Drain Plug

$5.13 $3.77
7 89422-WB002 89422-WB002 / Temp Sensor

$51.89 $38.06
7 89422-WB002 89422-WB002 / Temp Sensor

Coolant Temp Sensor

IA; AT RADIATOR

$51.89 $38.06
8 90118-WB491 90118-WB491 / Temp Sensor O-Ring

$5.11 $3.75
9 16571-WB001 16571-WB001 / Upper Hose

TO 08/2015

$54.73 $40.15
9 16571-WB002 16571-WB002 / Upper Hose

FROM 08/2015

$40.29 $29.55
10 90118-WB435 90118-WB435 / Hose Clamp

Upper Hose Clamp

$5.09 $3.73
11 16572-WB001 16572-WB001 / Lower Hose

TO 08/2015

$49.29 $36.15
11 16572-WB002 16572-WB002 / Lower Hose

FROM 08/2015

$40.29 $29.55
12 90118-WB435 90118-WB435 / Hose Clamp

Lower Hose Clamp

$5.09 $3.73
13 16480-WB001 16480-WB001 / Expansion Tank

Reservoir Tank

$48.82 $35.81
14 16405-WB001 16405-WB001 / Reservoir Cap

$36.50 $26.77
15 16261-WB001 16261-WB001 / By-Pass Hose

$39.33 $28.85
16 16323-WB004 16323-WB004 / Thermostat Housing

Thermostat Hsng

$77.01 $56.49
17 16326-WB001 16326-WB001 / Thermostat Hsng Gasket

$6.53 $4.79
18 16321-WB001 16321-WB001 / Water Inlet

$54.50 $39.97
19 90118-WB459 90118-WB459 / Thermostat

$23.35 $17.13
20 16268-WB002 16268-WB002 / Water Outlet Pipe O-Ring

Water Outlet Pipe

$108.05 $79.25
21 16268-WB002 16268-WB002 / Water Outlet Pipe O-Ring

$108.05 $79.25
22 16258-WB001 16258-WB001 / Water Outlet Pipe Gasket

$3.56 $2.61
No. Part # Part # / Description List Price Price
N/A 89661-WB001 89661-WB001 / ECM

IA; MANUAL TRANS

$575.79 $422.32
No. Part # Part # / Description List Price Price
N/A 89422-WB001 89422-WB001 / Coolant Temp Sensor

IA; AT ENGINE

$51.89 $38.06
