MAINTENANCE & LUBRICATION/FILTERS for 2012 Toyota Avalon

Select FILTERS Part

2012 Toyota Avalon

Change vehicle

No. Part # Part # / Description List Price Price
1 77001-06112 77001-06112 / Fuel Tank

- -
2 77601-07010 77601-07010 / Mount Strap

Tank Strap, RIGHT

$56.60 $41.52
3 77602-07010 77602-07010 / Mount Strap

Tank Strap, LEFT

$56.60 $41.52
4 90250-08019 90250-08019 / Mount Strap Pin

Tank Strap Pin, LEFT

$5.83 $4.28
4 90250-08019 90250-08019 / Mount Strap Pin

Tank Strap Pin, RIGHT

$5.83 $4.28
5 77631-06060 77631-06060 / Tank Shield

Protector

$66.14 $48.51
6 90080-11169 90080-11169 / Heat Shield Bolt

Protector Bolt

$0.66 $0.49
7 77201-07070 77201-07070 / Filler Pipe

$187.11 $137.24
8 77217-07010 77217-07010 / Filler Pipe Support

Filler Pipe Upper Support

$11.06 $8.11
9 77216-07010 77216-07010 / Filler Pipe Support

Filler Pipe Lower Support

$18.27 $13.41
10 77278-07030 77278-07030 / Filler Neck Protector

Filler Pipe Protector

$22.50 $16.51
11 77291-AC030 77291-AC030 / Shield

$29.28 $21.47
12 77391-20030 77391-20030 / Pocket O-Ring

Shield Retainer Ring

OUTER

$3.48 $2.55
13 77391-02040 77391-02040 / Pocket O-Ring

Shield Retainer Ring

INNER

$2.93 $2.15
14 77300-06040 77300-06040 / Filler Cap

$20.91 $15.34
15 77316-06070 77316-06070 / Filler Cap Gasket

$18.10 $13.27
16 77226-07010 77226-07010 / Breather Tube

$43.85 $32.16
17 77213-06040 77213-06040 / Connector Hose

Filler Hose

$42.44 $31.12
18 77203-06020 77203-06020 / Suction Tube

$37.50 $27.50
19 77404-06050 77404-06050 / Vent Hose

$16.12 $11.82
20 77209-06030 77209-06030 / Suction Tube

Pressure Line

$36.09 $26.47
21 77168-33050 77168-33050 / Suction Tube Plate

Upper Plate

$25.83 $18.95
22 77024-06020 77024-06020 / Suction Valve

Lower Plate

$37.84 $27.76
23 77169-33020 77169-33020 / Fuel Pump Gasket

Lower Plate Gasket

$15.37 $11.27
24 23300-0A020 23300-0A020 / Fuel Filter

AVALON

$38.23 $28.04
25 77785-06020 77785-06020 / Fuel Pump Harness

Harness

$7.10 $5.21
26 23280-20060 23280-20060 / Fuel Pressure Regulator

Pressure Reg

$150.67 $110.51
26 23280-20060 23280-20060 / Fuel Pressure Regulator

AVALON

$150.67 $110.51
27 23221-0A040 23221-0A040 / Fuel Pump

$343.09 $251.65
28 23249-0A020 23249-0A020 / Fuel Pump Cushion

$18.39 $13.49
29 77175-06020 77175-06020 / Fuel Filter Support

Fuel Pump Support

$10.11 $7.42
30 23217-0C010 23217-0C010 / Fuel Filter

Strainer

$14.28 $10.48
31 83320-07010 83320-07010 / Fuel Gauge Sending Unit

Sending Unit

$77.81 $57.07
31 83320-07010 83320-07010 / Fuel Gauge Sending Unit

AVALON

$77.81 $57.07
No. Part # Part # / Description List Price Price
1 13470-31030 13470-31030 / Crankshaft Pulley

$298.14 $218.67
2 90119-16004 90119-16004 / Crankshaft Pulley Bolt

$7.93 $5.82
3 13521-0P011 13521-0P011 / Crankshaft Gear

$28.04 $20.57
4 11310-0P041 11310-0P041 / Lower Timing Cover

Timing Cover

$845.33 $620.02
5 90311-A0005 90311-A0005 / Seal

Crankshaft Seal

$17.24 $12.64
6 13506-0P011 13506-0P011 / Timing Chain

$251.13 $184.20
7 13540-0P010 13540-0P010 / Chain Tensioner

Tensioner

$79.53 $58.33
8 13559-0P010 13559-0P010 / Chain Guide

Tension Arm

$36.43 $26.72
9 13561-0P010 13561-0P010 / Chain Guide

Vibration Damper

$99.49 $72.98
10 11201-0P020 11201-0P020 / Valve Cover

Valve Cover, RIGHT

$349.82 $256.58
10 11202-0P020 11202-0P020 / Valve Cover

Valve Cover, LEFT

$374.93 $274.99
11 11214-0P040 11214-0P040 / Valve Cover Gasket

Valve Cover Gasket, LEFT

$17.44 $12.79
11 11213-0P010 11213-0P010 / Valve Cover Gasket

Valve Cover Gasket, RIGHT

$15.86 $11.63
12 12180-0H012 12180-0H012 / Filler Cap

$11.84 $8.69
13 90080-43025 90080-43025 / Filler Cap O-Ring

Filler Cap Gasket

$5.86 $4.29
14 15301-0P010 15301-0P010 / Dipstick

$16.09 $11.80
15 12142-0P010 12142-0P010 / Tube

Guide Tube

UPPER

$18.07 $13.26
16 11452-0P010 11452-0P010 / Guide Tube

LOWER

$11.61 $8.52
17 04152-YZZA1 04152-YZZA1 / Oil Filter

AVALON

$5.41 $3.95
18 15620-31060 15620-31060 / Filter Cover

Cap

$35.11 $25.75
19 90301-79006 90301-79006 / Oil Filter Hsng Gasket

Cap Gasket

$5.00 $3.67
20 15643-31050 15643-31050 / Drain Plug

$4.45 $3.27
21 96723-35028 96723-35028 / Oil Filter Hsng O-Ring

Drain Plug Seal

$3.88 $2.84
22 15115-0P030 15115-0P030 / Oil Pump Cover

Oil Pump

$29.88 $21.91
23 15103-0P010 15103-0P010 / Rotor Assembly

Rotor

$54.82 $40.21
24 12102-0P020 12102-0P020 / Oil Pan

Lower Oil Pan

$187.77 $137.71
25 12101-0P040 12101-0P040 / Oil Pan

Upper Oil Pan

$244.48 $179.32
26 12121-0P010 12121-0P010 / Oil Pan Baffle

Baffle Plate

$54.82 $40.21
27 15104-31120 15104-31120 / Oil Pick-Up

Strainer

$50.22 $36.83
28 15147-0P020 15147-0P020 / Strainer Gasket

$4.40 $3.22
