HVAC/CONDENSER, COMPRESSOR & LINES for 1997 Toyota RAV4

Select CONDENSER, COMPRESSOR & LINES Part

1997 Toyota RAV4

Change vehicle

No. Part # Part # / Description List Price Price
1 88460-42021 88460-42021 / Condenser

$389.53 $285.70
2 90099-32130 90099-32130 / Fan Blade Bushing

Condenser Upper Mount

$3.02 $2.21
3 88467-16090 88467-16090 / Condenser Cushion

Condenser Lower Mount

$4.47 $3.28
4 88469-28010 88469-28010 / Pipe Retainer

Condenser Collar

$2.79 $2.05
5 90119-06336 90119-06336 / Condenser Mount Bolt

$0.39 $0.29
6 88471-20050 88471-20050 / Dehydrator

$72.74 $53.35
6 88471-20050 88471-20050 / Dehydrator

Drier

RAV4

$72.74 $53.35
7 88472-42010 88472-42010 / Dehydrator Bracket

$49.22 $36.10
8 88320-42010-84 88320-42010-84 / Compressor Assembly

- -
8 88320-42010-84 88320-42010-84 / Compressor Assembly

Compressor

RAV4

- -
9 90099-04356 90099-04356 / Compressor Assembly Mount Bolt

$3.10 $2.28
10 88899-22260 88899-22260 / Compressor Assembly Mount Stud

$5.78 $4.23
11 90178-A0016 90178-A0016 / Child Seat Bracket Nut

Compressor Assembly Nut

$1.09 $0.81
12 88410-42010 88410-42010 / Clutch

$211.71 $155.28
13 88411-42010 88411-42010 / Clutch Coil

Magnet

- -
13 88411-42010 88411-42010 / Clutch Coil

RAV4

- -
14 88412-2A010 88412-2A010 / Rotor

$260.38 $190.98
15 88403-12030 88403-12030 / Clutch Plate & Hub Assembly

Hub

- -
15 88403-12030 88403-12030 / Clutch Plate & Hub Assembly

RAV4

- -
16 88711-42010 88711-42010 / Discharge Hose

$163.48 $119.90
17 88688-42010 88688-42010 / Discharge Hose Bracket

$43.41 $31.84
18 88569-42020 88569-42020 / Discharge Hose Clamp

- -
19 88712-42041 88712-42041 / Suction Hose

FRONT

$132.88 $97.47
20 88717-42051 88717-42051 / Suction Hose

REAR

$144.04 $105.65
21 88688-42100 88688-42100 / Suction Hose Upper Bracket

- -
22 88688-42120 88688-42120 / Suction Hose Lower Bracket

$32.39 $23.75
23 88716-42010 88716-42010 / Pipe

TO CONDENSER

$39.12 $28.69
24 88706-42030 88706-42030 / Pipe

TO DEHYDRATOR

$256.93 $188.44
25 88716-42070 88716-42070 / Pipe

TO EVAPORATOR

$85.63 $62.81
26 88688-42060 88688-42060 / Pipe Bracket

TO DEHYDRATOR

$39.83 $29.22
27 88688-42040 88688-42040 / Pipe Bracket

TO EVAPORATOR

$35.31 $25.90
28 88718-12280 88718-12280 / Packing Retainer

Pipe Clamp

$2.42 $1.78
29 88645-20050 88645-20050 / High Pressure Cut-Off Switch

Pressure Switch

RAV4

$39.78 $29.17
No. Part # Part # / Description List Price Price
N/A 88360-30310 88360-30310 / Shaft Seals

RAV4

$76.85 $56.36
N/A 88712-42030 88712-42030 / Suction Hose

RAV4; FROM 2/96; DEALER AC

- -
No. Part # Part # / Description List Price Price
N/A 88336-42020 88336-42020 / Sensor

RAV4

$137.65 $100.96
N/A 88335-28020 88335-28020 / Gasket Kit

Overhaul Gasket Set

RAV4

$64.98 $47.67
