FUEL SYSTEM/FUEL SYSTEM COMPONENTS for 1996 Toyota RAV4

Select FUEL SYSTEM COMPONENTS Part

1996 Toyota RAV4

Change vehicle

No. Part # Part # / Description List Price Price
1 77001-42051 77001-42051 / Fuel Tank

- -
2 77601-42030 77601-42030 / Fuel Tank Mount Strap

Fuel Tank Mount Strap, RIGHT

2 DOOR

$70.37 $52.78
2 77601-42030 77601-42030 / Fuel Tank Mount Strap

Fuel Tank Mount Strap, LEFT

2 DOOR

$70.37 $52.78
2 77601-42040 77601-42040 / Fuel Tank Mount Strap

Fuel Tank Mount Strap, LEFT

4 DOOR

$70.37 $52.78
2 77601-42040 77601-42040 / Fuel Tank Mount Strap

Fuel Tank Mount Strap, RIGHT

4 DOOR

$70.37 $52.78
3 77643-42010 77643-42010 / Tank Shield

Tank Shield, LEFT

FRONT, OUTER

$20.08 $15.06
3 77642-42010 77642-42010 / Tank Shield

Tank Shield, RIGHT

FRONT, OUTER

$71.77 $53.83
4 77606-42010 77606-42010 / Tank Shield

FRONT, INNER

$116.42 $87.32
5 77659-42010 77659-42010 / Tank Shield

Tank Shield, LEFT

SIDE

$57.49 $43.12
5 77658-42010 77658-42010 / Tank Shield

Tank Shield, RIGHT

SIDE

$64.99 $48.74
6 77310-35080 77310-35080 / Cap

Filler Cap

TO 3/98

$29.36 $22.02
7 77316-16010 77316-16010 / Fuel Cap Gasket

Filler Cap Gasket

$16.41 $12.31
8 77201-42081 77201-42081 / Filler Pipe

$210.00 $157.50
9 77277-42011 77277-42011 / Filler Pipe Protector

$104.64 $78.48
10 77290-42010 77290-42010 / Filler Pipe Shield

UPPER

$40.00 $30.00
11 77293-32020 77293-32020 / Inner Shield

Filler Pipe Shield

LOWER

$48.21 $36.16
12 77213-42020 77213-42020 / Connector Hose

$52.87 $39.65
13 77011-10060 77011-10060 / Lower Pipe

$41.78 $31.34
14 77017-42020 77017-42020 / Vent Tube

$104.30 $78.23
15 77023-32030 77023-32030 / Filter

$13.25 $9.94
16 77012-42030 77012-42030 / Breather Tube

$70.37 $52.78
17 23220-74021 23220-74021 / Fuel Pump

Fuel Pump Assembly

- -
17 23220-74021 23220-74021 / Fuel Pump

RAV4

- -
18 23217-74021 23217-74021 / Fuel Filter

Filter

$12.10 $9.08
19 23219-03010 23219-03010 / Fuel Strainer Clip

Filter Clip

$1.12 $0.84
20 23280-74160 23280-74160 / Fuel Pressure Regulator

Regulator

$187.13 $140.35
20 23280-74160 23280-74160 / Fuel Pressure Regulator

RAV4

$187.13 $140.35
21 83320-49055 83320-49055 / Sending Unit

PUMP

$172.51 $129.38
21 83320-49065 83320-49065 / Sending Unit

TANK

$95.71 $71.78
21 83320-49065 83320-49065 / Sending Unit

Fuel Gauge Sending Unit

RAV4

$95.71 $71.78
22 77203-42010 77203-42010 / Sending Unit Bracket

$107.14 $80.36
23 77016-42030 77016-42030 / Vent Tube

RETURN

$24.74 $18.56
24 95337-08020 95337-08020 / Return Hose

$10.14 $7.61
25 90467-13061 90467-13061 / Hose Clamp

Return Hose Clamp

$1.01 $0.76
26 77018-42040 77018-42040 / Vent Tube

FUEL EVAPORATION

$75.71 $56.78
27 77179-26011 77179-26011 / Gasket

Vent Tube Gasket

$2.64 $1.98
28 77380-26010 77380-26010 / Valve

FUEL CUT OFF, #1

$15.08 $11.31
29 77420-26010 77420-26010 / Cut-Off Valve

Valve

FUEL CUT OFF, #2

$15.08 $11.31
No. Part # Part # / Description List Price Price
N/A 78180-42020 78180-42020 / Throttle Cable

RAV4; W/O CRUISE CONTROL

$160.01 $120.01
N/A 22270-74171 22270-74171 / Idle Speed Control

RAV4

$352.46 $264.35
N/A 23207-46010 23207-46010 / Damper

RAV4

$76.77 $57.58
No. Part # Part # / Description List Price Price
N/A 23814-74071 23814-74071 / Fuel Rail

RAV4

$91.08 $68.31
N/A 23209-74140 23209-74140 / Injector

RAV4

$202.22 $151.67
